  • 名称：Optical Fiber Ribbon Cable

    Ribbon cable are more and more popular, small volume and lightOur Ribbon cable till to 24core indoor

  • 产品参数：



    Description

    Ribbon cable are more and more popular, small volume and light

    Our Ribbon cable till to 24core indoor

    We used all Muliti-mode fiber are from Germany is J-fiber, Here you can see our fiber stock, we control the quality 100% and test them 100% from the raw material to final finished products.



    Structure&Capability

    Structure

    Description

    Optical Fiber Ribbon、Inner Jacket、Strength Member、Outer Jacket.

    Fiber

    SM: G652D、G655、G657 Or other single-mode optical fibers.
    MM: A1a、A1b Or other multi-mode fibers.

    Strength Member

    Aramid yarn or other high strength yarn.

    Jacket

    Materials: low smoke halogen-free flame retardant polyolefin (LSZH) or other materials
    Color: Color as specified by standard or other color.

    Features

    Application

    Used as cable in indoor premises distribution system.
    used for MPO active adaptor.
    Used for transmission between indoor transmission equipment and voice data processing optical interface device.

    Characteristic

    Good mechanical and environmental performance.
    Flame retardant (or non-flame retarding)characteristic meets the requirements of relevant standards.
    Mechanical and physical properties of jacket meet the requirements of relevant standards.
    Soft, flexible, easy to lay and splice, and with big capacity data transmission.

    Temperature

    -20℃～+60℃

    Parameter

    Fiber Count

    Cable Dimension (mm)

    Cable weight
    (kg)

    Tensile (N)

    Crush (N/10cm)

    Bending radius (mm)

    Long Term

    Short Term

    Long Term

    Short Term

    Static

    Dynamic

    4

    3.5×2.5

    8.4

    100

    200

    300

    1000

    10D

    20D

    6

    4.0×2.5

    9.3

    100

    200

    300

    1000

    10D

    20D

    12

    5.0×2.5

    12.0

    130

    440

    300

    1000

    10D

    20D

    24

    7.5×2.5

    15.2

    200

    660

    300

    1000

    10D

    20D


    Options

    Cable Dimension: The nominal cable dimension, or other customized dimension:

    Delivery Length: 1.0km or 2.0km, or other customized length;

    Other requirements: other customized special request.
